Harman - JBL Professional AE (Application Engineered) Series AM7215/95
Speaker - for PA system - 600 Watt - 2-way - white
Product Description
Additional Details
- Special Delivery: None
What's Included
| Main Specifications | |
|---|---|
| Product Description | JBL Professional AE (Application Engineered) Series AM7215/95 - speaker - for PA system |
| Product Type | Speaker - for PA system |
| Speaker Type | 2-way - passive |
| Continuous Power | 600 Watt |
| Peak Power | 2400 Watt |
| Nominal Impedance | 8 Ohm |
| Color | White |
| Image Color Disclaimer | The displayed product image may be a different color |
| Dimensions (WxDxH) | 16.5 in x 19.8 in x 30.7 in |
| Weight | 59.97 lbs |
| General | |
| Product Type | Speaker - for PA system |
| Features | Progressive Transition (PT) waveguide technology, bi-amp/passive switchable |
| Enclosure Color | White |
| Image Color Disclaimer | The displayed product image may be a different color |
| Enclosure Material | Birch plywood |
| Design Features | DuraFlex finish, trapezoidal design |
| Miscellaneous | |
| Compliant Standards | MIL-STD-810, IEC 529/IPx3 |
| Connections | |
| Connector Type | Speakers input (speakON NL4 (4 pole)) ¦ Speakers input (screw-type) |
| Dimensions & Weight | |
| Width | 16.5 in |
| Depth | 19.8 in |
| Height | 30.7 in |
| Weight | 59.97 lbs |
| Speaker System | |
| Speaker Type | 2-way - passive |
| Continuous Power | 600 Watt |
| Peak Power | 2400 Watt |
| Frequency Response (+/-3dB) | 40 - 20000 Hz |
| Frequency Response (-10dB) | 34 - 20000 Hz |
| Nominal Impedance | 8 Ohm |
| Max Output Level (Max SPL) | 124 dB |
| Sensitivity | 96 dB |
| Crossover Frequency | 1200Hz |
| Coverage | 90° x 50° can be rotated to 50° x 90° |
| Recommended Placing | Suspended |
| Detachable Grilles | Yes |
| Speaker System Details | |
| Driver Details | Speaker: woofer driver - 15" - Differential Drive - dual voice coil ¦ Speaker: tweeter driver - 1.5" - compression driver |
