Vertiv - Vertiv Liebert EXS V-Model EXSV-30KN
UPS - AC 208/220 V - 30 kW - 30000 VA - 3-phase - valve regulated lead-acid (VRLA)
Product Description
Additional Details
- Special Delivery: None
What's Included
| Main Specifications | |
|---|---|
| Product Description | Vertiv Liebert EXS V-Model EXSV-30KN - UPS - 30 kW - 30000 VA - VRLA |
| Device Type | UPS - external |
| Input Wiring | 3-phase |
| Input Voltage | AC 208/220 V |
| Output Voltage | AC 208/220 V |
| Power Capacity | 30 kW / 30000 VA |
| Input Connectors | Hardwire 5-wire |
| Battery | Valve regulated lead-acid (VRLA) |
| Run Time (Up To) | 10 min at full load |
| Included Accessories | RDU120 communication card |
| Dimensions (WxDxH) | 23.6 in x 39.4 in x 78.7 in |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | UPS - external |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Included Accessories | RDU120 communication card |
| Features | Double conversion, built-in maintenance bypass |
| Compliant Standards | RoHS, Energy Star 2.0, WEEE |
| Environmental Parameters | |
| Max Operating Temperature | 104 °F |
| Battery | |
| Technology | Valve regulated lead-acid (VRLA) |
| Run Time (Up To) | 26 min at half load |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 208/220 V |
| Input Wiring | 3-phase |
| Input Connectors | Hardwire 5-wire |
| Output Voltage | AC 208/220 V |
| Power Capacity | 30 kW / 30000 VA |
| Efficiency | 93.4% |
| Power Factor (PF) | 1.0 |
| Dimensions & Weight | |
| Width | 23.6 in |
| Depth | 39.4 in |
| Height | 78.7 in |
